chipset
|
Qualcomm Atheros 9533
|
|
Standard
|
IEEE802.11/b/g/n, MIMO technology
|
|
Memory
|
512Mbit(64MByte) DDR2 RAM
|
|
Flash
|
64Mbit(8MByte)
|
|
Interface
|
2 * 10/100 RJ45 WAN/LAN Port
|
|
1*DC power jack
|
|
1 x Reset button(Reset & Factory Defaults)
|
|
LED Light
|
WLAN, WAN, LAN, Power |
|
Antenna
|
Internal 12dbi dual polarized antennas
|
|
Power Supply
|
PoE: 802.3af (24V passive PoE optional)
|
|
Power consumption
|
1W
|
|
Frequency
|
2.4-2.4835Ghz
|
| RF Power |
<27dBm/500mw (Typical) |
|
Wireless signal rate
|
11n: Up to 300Mbps(dynamic)
|
|
11g: Up to 54Mbps(dynamic)
|
|
11b: Up to 11Mbps(dynamic)
|
|
Modulation
|
OFDM = BPSK,QPSK, 16-QAM, 64-QAM
|
|
DSSS = DBPSK, DQPSK, CCK
|
|
Throughput
|
300Mbps
|
|
Operation mode
|
AP, Gateway, Repeater
|
|
Wireless Security
|
64/128-bit WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption
|
|
Wireless Function
|
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
|
|
WAN Protocols
|
Dynamic IP/Static IP/PPPoE/L2TP(Dual Access) /PPTP(Dual Access)
|
|
Firewall
|
DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter IP andMAC Address Binding
|
|
|
PPTP, L2TP, IPSec (ESP Head)
|
|
Package Contents
|
300Mbps wireless CPE; Ethernet Cable
Quick Installation Guide; Install accessories
|
|
System Requirements
|
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8,Windows 10, MAC OS, NetWare, UNIX or Linux
|
|
Environment
|
Operating Temperature: -30°C~70°C (-22℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
|
