| Dimension |
273*182*20mm |
| OS |
Windows 11 Pro |
| CPU |
Intel Jasper Lake processor Celeron N5100, (Optional i5 8200Y CPU) |
| Weight |
Device unit: 980g |
| Display |
10.1 inch IPS 16:10 (10 points touch G+G) |
| Memory |
8GB RAM+ 256GB ROM |
| Battery Capacity |
12000mAH + 2400mAH Dual battery,Support hot swap |
| Resolution |
1920*1200 IPS LCD,500 Nit (optional 1000 nits high brightness screen) |
| Interface Configuration |
1. Type-A ：USB3.0 x12. HDMI ：HDMI Type A x1,Audio and video output3. RJ45 Ethernet ：10/100/1000M x14. 3.5mm Headphone： ∮3.5mm Standard headphone interface x1 5. DB9 ：RS232 9-pin serial port x1 6. DC power interface: DC 12V 4A ∮4.0mm power interface x1 |
| TF card |
Extended external storage x1 |
| SIM |
SIM card x2 in tablet |
| 1D/2D barcode (Optional) |
Support N4680 Series 2D Scan Engines |
| UHF RFID Internal (Optional) |
Output power range：18-26 dBm；Receiving sensitivity< -70dBm；Readdistance：2-3 meter |
| UHF RFID External (Optional) |
Output power range：18-26 dBm；Receiving sensitivity< -70dBm；Readdistance：4-5 meter |
| Fingerprint module (Optional) |
AFM60,1:N identification or 1:1 verification |
| High precision GNSS (Optional) |
Module TAU1201,Sub meter level，positioning accuracy：0.25-1 seconds，Support Beidou、GPS、GLONASS；Capture sensitivity:-158 dBm； Cold start：24seconds； Hot start：1seconds |
| IP rating |
IP67 |
| Drop Resistance |
1.22m Drop, in operation status |
| Camera |
Front Camera 5.0M+Rear Camera 13M.0M(Support flash LED) |
| Extensive Slot |
Bottom 8PIN + Back 16PIN |
| 3G/4G |
TDD-LTE：B40 FDD-LTE：B1/B2/B3/B4/B5/B7/B8/B28 WCDMA：B1/B2/B4/B5/B8 GSM：B2/B3/B5/B8 |
| Operate Temperature |
-20°C ～ 60 °C |
| Store Temperature |
-30°C ～ 70 °C |
| NFC/RFID |
ISO/IEC14443，ISO/IEC15693，MIFARE，Felica，Read distance：3-5cm，Front |
| Wifi |
802.11a/b/g/n/ac, Wireless AP ( Mobile AP )2.4G, 5G |
| Bluetooth |
BT5.1 (BLE) |
| GPS |
Support Beidou+GPS+glonass；Capture sensitivity:-163 dBm；Cold start：35seconds，Hot start：1seconds |
| Certification standards |
Military 810G, EU CE, US FCC |
| Accessories |
Standard include Power adaper with USB Cable,Hand strap, optional Docking Charger,Car Holder,Back strap,Spare Battery,Stylus,Car Charger,etc.. |
